DAHUA 5MP STARLIGHT HDCVI IR30M EYEBALL CAMERA BUILT-IN MIC IP67
REF L-DH-HAC-HDW1500TLMN-A-0280B-S2
$42.99
En existencias: 4 disponibles
1
Guardar este producto para más tarde
DAHUA 5MP STARLIGHT HDCVI IR30M EYEBALL CAMERA BUILT-IN MIC IP67
Información del producto
UPC: L-DH-HAC-HDW1500TLMN-A-0280B-S2
Marca: DAHUA
HAC-HDW1500TLM-A
5MP Starlight HDCVI IR Eyeball Camera
> * The parameters and datasheets below can only be applied to1500-S2 series.
> * In order to use the 5MP 16:9 HDCVI camera, the firmware of XVR must be upgraded to V4.001.0000001.0.R.200908 or later version.
> Max 25 fps@5MP (16:9 video output)
> CVI/CVBS/AHD/TVI switchable> 3.6 mm fixed lens (2.8mm optional)
> Built-in mic (-A)
> Max. IR length 30 m, Smart IR
> IP67, DC12V
- Specifications
- Accessories
- Download
-
Camera Image Sensor 5MP CMOS Max. Resolution 2880 (H) × 1620 (V) Pixel 5MP Scanning System Progressive Electronic Shutter Speed PAL: 1/25 s–1/100000 s
NTSC: 1/30 s–1/100000 sS/N Ratio > 65 dB Min. Illumination 0.005 Lux/F1.6, 30IRE, 0 Lux IR on Illumination Distance 30 m (98.4 ft) Illuminator On/Off Control Auto; manual Illuminator Number 1 (IR light) Pan/Tilt/Rotation Range Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°Lens Lens Type Fixed lens Mount Type M12 Focal Length 2.8mm; 3.6mm; Max. Aperture F1.6 Field of View 2.8mm:H:111° V:58° D:132°
3.6mm: H:92° V:48° D:109°Iris Type Fixed Close Focus Distance 2.8 mm: 0.9 m (3.0 ft)
3.6 mm: 1.6 m (5.2 ft)DORI Distance Lens Detect Observe Recognize Identify 2.8 mm 63.6 m(208.7 ft) 25.4 m(83.3 ft) 12.7 m(41.7 ft) 6.4 m(21.0ft) 3.6 mm 80.0 m(262.5 ft) 32.0 m(105.0 ft) 16.0 m(52.5 ft) 8.0 m(26.2 ft) Video Frame Rate CVI:
PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps;
NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps
AHD:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
TVI:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
CVBS:
PAL: 960H;
NTSC: 960HResolution 5M (2880 × 1620);
4M (2560 × 1440);
1080P (1920 ×1080);
960 H (960 × 576/960 × 480)Day/Night Auto switch by ICR BLC BLC/HLC/DWDR WDR DWDR White Balance Auto; Area WB Gain Control Auto/Manual Noise Reduction 2D NR Smart IR Yes Mirror Off/On Privacy Masking Off/On (8 area, rectangle) Certifications Certifications CE (EN55032, EN55024, EN50130-4, EN62368-1)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)Port Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port Audio Input
