Name: DAHUA 2M FULL-COLOR STARLIGHT HDCVI EYEBALL CAMERA IP67 METAL
Brand: DAHUA
SKU: l-DH-HAC-HDW1239TLQN-LED-0280B-S2
Price: 33.99 USD
Availability: InStock

DAHUA 2M FULL-COLOR STARLIGHT HDCVI EYEBALL CAMERA IP67 METAL

Información del producto

UPC: L-DH-HAC-D1A51N-0280B-S2

Marca: DAHUA

HAC-HDW1239TLQ(-A)-LED

2MP Full-color HDCVI Quick-to-install Eyeball Camera

> * The parameters and datasheets below can only be applied to 1239-S2 series

> 24/7 color imaging, Max. 30 fps@1080p

> 20 m illumination distance
> Super Adapt, 130 dB true WDR, 3D NR
> Built-in mic (-A)
> Quick-to-install eyeball saves installation time
> 3.6 mm fixed lens (2.8 mm optional)
> CVI/CVBS/AHD/TVI switchable
> IP67, DC 12 V

Especialización
Accesorios
Descargar

Selector de productos

Camera

Image Sensor

1/2.8" CMOS

Max. Resolution

1920 (H) × 1080 (V)

Pixel

2MP

Scanning System

Progressive

Electronic Shutter Speed

PAL: 1/25 s–1/100,000 s
NTSC: 1/30 s–1/100,000 s

S/N Ratio

> 65 dB

Min. Illumination

0.001 Lux/F1.6, 30IRE, 0 Lux LED on

Illumination Distance

20 m (65.6 ft)

Illuminator On/Off Control

Auto; manual

Illuminator Number

Pan/Tilt/Rotation Range

Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°

Lens

Lens Type

Fixed lens

Mount Type

M12

Focal Length

2.8 mm; 3.6 mm

Max. Aperture

F1.6

Field of View

2.8 mm: H: 107°; V: 56°; D: 127°
3.6 mm: H: 86°; V: 46°; D: 101°

Iris Type

Fixed iris

Close Focus Distance

2.8 mm: 0.7 m (2.3 ft)
3.6 mm: 1.1 m (3.6 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm

43.9 m(144 ft)

17.5 m(57.4 ft)

8.8 m(28.9 ft)

4.4 m(14.4 ft)

3.6 mm

53.7 m(176.2 ft)

21.5 m(70.5 ft)

10.7 m(35.1 ft)

5.4 m(17.7 ft)

Video

Frame Rate

CVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
AHD:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
TVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
CVBS:
PAL: 960 × 576H;
NTSC: 960 × 480H

Resolution

1080p (1920 × 1080); 960H (960 × 576/960 × 480)

BLC

BLC/WDR/HLC

WDR

130 dB

White Balance

Auto; Area WB

Gain Control

Auto; manual

Noise Reduction

3D NR

Smart Light

Yes

Mirror

Off/On

Privacy Masking

Off/On (8 area, rectangle)

Certifications

CE (EN55032, EN55024, EN50130-4)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)

Port

Video Output

Video output choices of CVI/TVI/AHD/CVBS by one BNC port

Audio Input

One channel built-in mic (-A)

Power

Power Supply

12 V ±30% DC

Power Consumption

Max 3.3 W (12 V DC, LED on)

Environment

Operating Temperature

–40 °C to +60 °C (–40 °F to 140 °F); < 95% (non-condensation)

Storage Temperature

–40 °C to +60 °C (–40 °F to 140 °F); < 95% (non-condensation)

Protection Grade

IP67

Structure

Casing

Metal inner core + plastic cover + plastic pedestal

Camera Dimensions

φ97.1 mm × 92.9 mm (φ3.82" × 3.66")

Net Weight

0.22 kg (0.49 lb)

Gross Weight

0.28 kg (0.62 lb)
